USE
Cardboard
Plastic
Mixed waste
Incineration waste
FEATURES
Standard containers up to 38 m³
Large infeed opening
Reliable and easy to use
Intelligent SMART technology
CAPACITY
20 m³
24 m³
27 m³
30 m³
32 m³
35 m³
36 m³
STATIONARY WASTE COMPACTORS FOR LARGE AMOUNTS OF WASTE
Europress Duo and DuoMax are robust stationary waste compactors designed for heavy usage. They are ideal solution for large amounts of various dry materials. Loading is easy due to their large infeed openings.
As stationary compactors, the containers of DuoMax and Duo are detached for transportation while the press units stay firmly attached on the ground. The waste compactors can be equipped with shafts for through-wall or multi-floor loading, forming a safe closed structure. The design also supports various loading devices e.g. conveyors.
DuoMax and Duo can be supplied with a range of accessories e.g. bin lifts and lid opening systems. Several standard container capacities ranging up to 38 m² are available together with floating roof option, to achieve extremely high payloads. Waste compactors can be utilized 24/7 especially with a secondary container in reserve.
Intelligent SMART technology on the compactors contributes to more cost-efficient and safe operation. Device settings can be individually adjusted to best meet various waste management requirements. The compactors monitor their usage and adapt to anomalies in order to protect both the operator and the components.
DuoMax & Duo compactors feature Europress SMART connectivity readiness as standard, enabling integration to the Europress SMART Fleet Management system. The system provides insights on asset data and tools for streamlined fleet management.
DuoMax compressing plastic waste in a Tamro logistics center
Finland’s leading distributor and service provider of pharmaceuticals and health products Tamro uses 10 Europress devices.
Additional information
DuoMax | Duo
Infeed aperture (mm)
1 850 x 1 300 mm | 1 500 x 900
Infeed height, ground level (mm)
1 480 / 1 300 | 1 480 / 1 300
Compaction force (t)
35 / 40* | 25
Press cycle time (s)
66 / 35* | 42
Capacity (cardboard) (m³ /h)
78 / 147* | 69
Motor (kW*)
5,5 / 7,5 | 5,5
Power supply
400 V, 50 Hz, 3×C16 A (Duo / DuoMax)
400 V, 50 Hz, 3×C32 A* (DuoMax)
Blue color RAL 5017
Standard filling hopper
Lift hook rear (container)
Front rollers on container (roll-off)
Container not present switch (safety limit)
Waste return block (stop wires & tarpaulin)
Intelligent SMART technology
Europress SMART connectivity readiness
Custom RAL color
Guide rails
Additional controls e.g. emergency stops
Rear rollers on container (roll-off)
Custom filling hopper
2-phase discharge door opening mechanism
Long handle discharge door opening mechanism
Hydraulic discharge door opening system
Bin lift (integrated / stationary)
Lid opening system (hydraulic / electronic)
Code start system
Auto start system
7.5 kW power unit
Low feed set up
Floating roof container 20-36 m²
Reserve container
DuoMax / Duo press unit
Length 2,730 / 2,160 mm
Width 2,300 / 1,900 mm
Height 2,440 / 2,260 mm
Weight 2,640 / 2,020 kg
Container 20 m³
Length 4,510 mm
Width 2,500 mm
Height 2,730 mm
Weight 2,300 kg
Container 24 m³
Length 5,330 mm
Width 2,500 mm
Height 2,730 mm
Weight 2,460 kg
Container 27 m³
Length 5,940 mm
Width 2,500 mm
Height 2,730 mm
Weight 2,680 kg
Container 30 m³
Length 6,550 mm
Width 2,500 mm
Height 2,730 mm
Weight 2,900 kg
Container 32 m³
Length 6,960 mm
Width 2,500 mm
Height 2,730 mm
Weight 3,000 kg
Container 35 m³
Length 6,675 mm
Width 2,500 mm
Height 3,070 mm
Weight 3,230 kg
