VERSATILE WASTE COMPACTOR WITH EXTRA LARGE FEED OPENING
An easy-to-use and efficient waste compactor equipped with an extra large feed opening, ideal for compressing large cardboard boxes. The spacious service door for the cylinder compartment provides effortless access to maintenance points. The compactor unit is attached to the container. With an efficient compression ratio waste compactors are highly efficient alternatives to waste skips. Quiet operating sound. Strong structure. Designed and manufactured in Finland for Nordic conditions. SMART technology ensures the energy efficiency of the waste compactor. CombiMax XL uses less electricity than traditional waste compactors.
In the Europress CombiMax XL waste compactors the compactor is attached to the container, which ensures hygiene at the location and while emptying. The CombiMax XL waste compactor is a space-saving, reliable and easy-to-use solution for waste management in, for example, shops, residential properties, industry, hotels and hospitals.
Media
Intelligent SMART technology on the compactors contributes to more cost-efficient and safe operation. Device settings can be individually adjusted to best meet various waste management requirements. The compactors monitor their usage and adapt to anomalies in order to protect both the operator and the components.
CombiMax Twin compactors feature Europress SMART connectivity readiness as standard.
ADDITIONAL INFORMATION
CombiMax XL
Infeed aperture (mm)
1,930 x 1,800
Infeed height front / side (mm)
1,850 x 1,500
Compaction force (t)
35 / 40
Press cycle time (s)
66 / 35
Capacity (m³ /h)
78 / 147
Noice level (dBa)
70
Motor (kW)
5.5 / 7.5
Power supply
400 V, 50 Hz, 3×C16 A
400 V, 50 Hz, 3×C32 A
Blue color RAL 5017
Standard filling hopper
Lift hooks front / rear
Europress SMART connectivity readiness
Tipping device
Lid opening mechanism (hydraulic/electric)
Custom RAL colour
Low infeed
Container top hinge
Code start system
Platform hopper
Additional controls e.g. emergency stops
Liquid removal system
Guiding rails
Ozone-generator/Cooler unit
Fire-extinguishing equipment
Underfloor heating system
Rollers, front/rear
More efficient 7.5 kW motor
Long handle discharge door opening mechanism
2-phase discharge door opening mechanism
CombiMax XL 13 m³
Length 5,194 mm
Width 2,500 mm
Height 2,900 mm
Weight 3,920 kg
CombiMax XL 14 m³
Length 5,494 mm
Width 2,500 mm
Height 2,900 mm
Weight 4,040 kg
CombiMax XL 17 m³
Length 5,994 mm
Width 2,500 mm
Height 2,900 mm
Weight 4,200 kg
CombiMax XL 20 m³
Length 6,580 mm
Width 2,500 mm
Height 2,900 mm
Weight 4,320 kg
CombiMax XL 22 m³
Length 6,984 mm
Width 2,500 mm
Height 2,900 mm
Weight 4,550 kg
